This 26 gallon still has it all! Comes with 3" stainless reflux column, (2) 2" element ports, for heating element adapters (adapters sold separately), tri clamp gasket and cover plate. This boiler can also be fired with a propane burner. The bottom of the boiler is flat and recessed.

Comes With:

• 3" Tri Clamp with 3" Silicone Gasket for connecting the column to a still.
• Commercial 3" face thermometer.
• 3" Tri Clamp dephlegmator connection with 3" Tri Clamp and 3" Silicone Gasket.
• Built in stainless Liebig condenser.
• 1/2" Hose barb connections on the condenser and dephlegmator (pre-condenser) for cooling water.
• Enough structured Copper Packing to fill the column.
• Dephlegmator (pre-condenser) for increasing and controlling proof.
• The column is 21" tall and the condenser is 30" long.
• 1.5" drain valve with down spout
• Carrying handles
• 2" filler port with tri clamp, gasket and cap
• 4" column connection
• Top quality construction, with beautifully rounded curves
• Built from heavy gauge 304 food grade Stainless Steel
• Polished to a mirror finish inside and out
• Base Diameter: 19 3/4"

DETERMINING TRI CLAMP SIZE

Tri Clamp sizes are determined by the outer diameter of the pipe or tubing, not the outer diameter of the flange or Tri Clamp itself. The flange of a Tri Clamp fitting typically has about a ½” inch greater diameter than the outside diameter of the pipe. This can become especially confusing when the Tri Clamp fitting has no pipe attached to it, as is the case with adapters, For instance, a  is not 1.5" inches in any dimension, but the Tri Clamp end will fit any other 1.5" Tri Clamp fitting.

If you have any doubts about what size Tri Clamp fittings your project needs, simply measure the outside diameter of the flange (dimension "B" below) and consult the chart below, or feel free to  .
